CS Series 6"x8" 2-way speakers 46CSC684

• 2-way 6"x8" speakers (pair)

• polypropylene woofer cone with polyester foam surround

• 1/2" polyetherimide (PEI) balanced dome tweeter

• handles up to 75 watts RMS (225 watts peak power)

• frequency response: 45-20,000 Hz

• sensitivity: 90 dB

• top-mount depth: 2-5/16"

• grilles not included

🔧 General

• Speaker Size: 6x8"

• Driver Design: 2-way

• Woofer Design: Cone

• Woofer Material: Polypropylene

• Woofer Surround: Polyester Foam

• Tweeter Design: 1/2" Balanced Dome

• Tweeter Material: PEI (Polyetherimide)

• Impedance: 4 Ohms

• Weather-Resistant: No

• Grilles Included: No

📊 Performance Specifications

• Sensitivity (1W @ 1 meter): 90 dB

• Frequency Response: 45 Hz – 20,000 Hz (20 kHz)

• Maximum RMS Power Handling: 75 Watts

• Peak Power Handling: 225 Watts

📐 Mounting Dimensions

• Top-Mount Depth: 2-5/16"

• Bottom-Mount Depth: 2-11/16"

• Mounting Height: 0.369"

• Cutout Diameter/Length: 0" (not provided)

• Frame Width: 5.495"

• Frame Length: 7.7"

• Two 2-way speakers

• Two 12" Lengths of speaker wire (tinned wire on one end and female quick slides on the other)

• 4 Red plastic wire caps

• Eight 1" Screws

• Owner's manual (English/ Spanish/ German/ French)
