CVP MINI 4-CHANNEL / 90WX4@2Ω CVPM400.4D
Cerwin-Vega CVPM Series Amplifiers – Power Meets Value
Upgrade your ride with the Cerwin-Vega CVPM Performance Series. These amps deliver the LOUD, clear sound Cerwin-Vega is known for—at a price that won’t break the bank.
Powerful & Affordable – Big sound, small price.
Built to Perform – Clean output, deep bass, crisp highs.
Reliable & Versatile – Mono and multi-channel options for any setup.
Get in. Turn it up. Live the LOUD life.
Cerwin-Vega CVPM Series Amplifiers – Power Meets Value
Upgrade your ride with the Cerwin-Vega CVPM Performance Series. These amps deliver the LOUD, clear sound Cerwin-Vega is known for—at a price that won’t break the bank.
Powerful & Affordable – Big sound, small price.
Built to Perform – Clean output, deep bass, crisp highs.
Reliable & Versatile – Mono and multi-channel options for any setup.
Get in. Turn it up. Live the LOUD life.
Cerwin-Vega CVPM Series Amplifiers – Power Meets Value
Upgrade your ride with the Cerwin-Vega CVPM Performance Series. These amps deliver the LOUD, clear sound Cerwin-Vega is known for—at a price that won’t break the bank.
Powerful & Affordable – Big sound, small price.
Built to Perform – Clean output, deep bass, crisp highs.
Reliable & Versatile – Mono and multi-channel options for any setup.
Get in. Turn it up. Live the LOUD life.
-
Power Rating (RMS)
90W x 4 @ 2Ω
60W x 4 @ 4Ω
240W x 2 @ 4Ω (Bridged)
Power Supply
Power Supply: Full WPM
Power Supply Threshold: 10.0V-17.0V (DC)
Idle Current: (0.7A)
Distortion
THD 4 (1KHZ @4Ω): 0.01%
S/N RATIO (A WEIGHTED @1W): -85dBA
S/N RATIO (A WEIGHTED @FP): -101.1dBA
Input Sensitivity
Hi/Low Level Input: 0.15mV-6.0V
Input Impedance
Low Level Input: 20KΩ
Output Stage
Output Impedance: 0.011Ω
Damping Factor (50Hz@4Ω): >70
Bandwidth (-3db): 10Hz-50KHz
Crossover (1-12dB/Oct)
Variable High-Pass: 15Hz-250Hz
Variable low-Pass:
Fuse Rating
1x20A
Dimensions
Length x Width x Height: 7.64”x3.7”x1.47” (194mm x 95mm x 37.3mm)
