Product highlights:
digital media receiver with AM/FM tuner (does not play discs)
adjustable floating 11.6" touchscreen display
fits single-DIN and double-DIN dash openings
RGB illuminated buttons and light bar
Bluetooth for hands-free calling and audio streaming
Smartphone features:
wired and wireless Apple CarPlay and Android Auto compatible
push-to-talk button for smartphone assistant (Siri or Google Assistant)
Audio/video features:
USB playback: MP3 and FLAC audio files and JPEG video files
10-band EQ with 7 preset EQ curves
subwoofer volume control
Expandability:
compatible with SiriusXM's aftermarket satellite radio tuner (sold separately, subscription required)
inputs: two rear USB inputs (2.1A), rear A/V input (RCA), two camera inputs
outputs: 6-channel preamp outputs (4-volt front, rear, sub)
Other information:
wired connection to parking brake required to access settings and other features on this receiver (the brake must be connected and set for video display)
built-in internal amp (16 watts RMS CTA-2006/60 watts peak x 4 channels)
works with iDatalink Maestro RR and RR2 modules
retains factory features in a wide selection of vehicles
displays engine performance data on touchscreen
CTA-2006 compliant
-
12" Touchscreen monitor
Source unit (15A fuse)
Wiring harness
GPS antenna (attached 9.75' cable terminated by SMB connector)
Microphone w/ bracket (attached 9.75' cable terminated by a mono-3.5mm connector
Self-adhesive GPS antenna pad
Mounting sleeve (pre-installed)
Trim-ring
Double-DIN bracket
8 Counter-sunk ISO-screws
8 Pan-head ISO-screws
4 Double-DIN bracket mounting screws
2 Radio removal tools
Quick Start Guide
Installation Guide
SiriusXM Satellite Radio Operation Guide
Registration/Warranty card
