2-Din Digital Media Receiver with Bluetooth DPX305MBT

General features:

• digital media receiver with AM/FM tuner

• high-contrast 3-line display with 3-zone variable-color illumination

• built-in Amazon Alexa

• plays USB drives with MP3, WMA, WAV, AAC, and high-res FLAC files

• Bluetooth with dual phone connection for hands-free calls and music streaming

Smartphone features:

• supports Kenwood Remote app

• Apple Music control (iPhone only)

• built-in iPod and iPhone control

Audio features:

• 13-band equalizer and digital time alignment

• high- and low-pass crossovers

• Drive EQ to compensate for road noise

Expandability:

• compatible with SiriusXM's aftermarket satellite radio tuner (sold separately, subscription required)

• inputs: front panel auxiliary and USB inputs

• outputs: 6-channel preamp outputs (2.5-volt front, rear, sub)

Other info:

• built-in MOSFET amplifier (22 watts RMS/50 peak x 4 channels)

• compatible with most factory steering wheel audio controls (adapter required)

General:

• RMS Power (CTA-2006): N/A

• RMS Power (Manufacturer): 22 watts

• Peak Output: 50 watts

Expandability:

• AUX Input: Front

• Audio/video Input: ---

• USB Input: Front

• USB Port Power: 1.5A

• Backup Camera Input: No

• Second Camera Input: No

• Preamp Outputs: 6-channel

• Sub Preamp Outputs: Yes

• Switchable Rear Preamp Outputs: No

• Memory Card Slot: USB

Smartphone Control:

• iPhone Compatibility: 5S and newer

• CarPlay: No

• Siri Control: Bluetooth

• Android Control: Yes

• Android Auto: No

• Alexa Voice Control: Yes

Tuner:

• FM Sensitivity: 8.2 dBf

• European Tuning: Yes

• Seek/Scan: Seek

• Radio Data System: Yes

File Playback:

• Music File Playback: MP3, WMA, AAC, WAV, FLAC

• High-res Playback: FLAC (96kHz)

Navigation Control:

• Navigation: ---

• Navigation App Compatible (iOS): ---

• Navigation App Compatible (Android): ---

Features & Specs:

• Bluetooth Compatible: Built-in

• Bluetooth Version: 4.2

• Satellite Radio Ready: SiriusXM 2.0

• HD Radio: No

• Video Screen: No

• Preamp Voltage: 2.5

• Screen Size: ---

• Screen Type: ---

• Display Color: Variable

• Key Button Color: Variable

• EQ Bands: 13

• Wireless Remote: Optional

• Steering Wheel Control Compatible: Adapter required

Dimensions:

• Chassis Depth: 4.225 inches

• Chassis Width: 7.015 inches

• Chassis Height: 3.955 inches

• Digital media receiver (10A fuse)

• Wiring harness

• Microphone w/ bracket (attached 10' cable terminated by a right-angle mono 3.5mm connector)

• 6 Pan-head screws (M5x8mm)

• 6 Flat-head screws (M5x8mm)

• Quick Start Gude

• Warranty Card
